SPECIAL TYPE THERMOCOUPLE FOR SECONDARY AND TAD

Thermocouple With Thermowell & Special Ceramic Coating & Heat Treatment

Type: Simplex, Ungrounded, Head: Die Cast. Alu. Weatherproof IP-67 Terminal & Ceramic Block,

Cable Entry: 1/2" Npt (F) With Cable Gland,

Sheath Dia: 6mm, Sheath Length: 1200mm Below Head,

Thermowell:- HRS 446, Well Dia: Od:22mm,

Process Conn: Adj Cs Flange, Pcd-70mm,

T/Well Length: 1200mm
